EGF Receptor (L858R Mutant Specific) (43B2) Rabbit mAb #3197

Item# Description List Price Web Price Qty
3197S EGF Receptor (L858R Mutant Specific) (43B2) Rabbit mAb - 100 µl $555.00
$499.50
ADD TO CART
*On-line ordering is for Canadian customers only. Web pricing is applicable only to orders placed online at www.neb.ca
X

Companion Products

Item# Description List Price Web Price Qty
12630P SignalFire™ Plus ECL Reagent - 20 ml $116.00
$104.40
ADD TO CART
12630S SignalFire™ Plus ECL Reagent - 100 ml $519.00
$467.10
ADD TO CART
12757P SignalFire™ Elite ECL Reagent - 20 ml $123.00
$110.70
ADD TO CART
12757S SignalFire™ Elite ECL Reagent - 100 ml $558.00
$502.20
ADD TO CART
2232L EGF Receptor Antibody - 300 µl $901.00
$810.90
ADD TO CART
2232S EGF Receptor Antibody - 100 µl $372.00
$334.80
ADD TO CART
2963S EGF Receptor (T43) Antibody - 100 µl $372.00
$334.80
ADD TO CART
3265S EGF Receptor (V279) Antibody - 100 µl $372.00
$334.80
ADD TO CART
4405S EGF Receptor (15F8) Rabbit mAb - 100 µl $372.00
$334.80
ADD TO CART
54359S EGF Receptor (D1D4J) XP® Rabbit mAb (Neutralizing) - 100 µl $419.00
$377.10
ADD TO CART
54359T EGF Receptor (D1D4J) XP® Rabbit mAb (Neutralizing) - 20 µl $174.00
$99.00
ADD TO CART
6883P3 SignalFire™ ECL Reagent - 50 ml $43.00
$38.70
ADD TO CART
6883S SignalFire™ ECL Reagent - 500 ml $370.00
$333.00
ADD TO CART
7074P2 Anti-rabbit IgG, HRP-linked Antibody - 100 µl $109.00
$98.10
ADD TO CART
7074S Anti-rabbit IgG, HRP-linked Antibody - 1 ml $203.00
$182.70
ADD TO CART
7074V Anti-rabbit IgG, HRP-linked Antibody - 5 ml $646.00
$581.40
ADD TO CART
7727L Biotinylated Protein Ladder Detection Pack - 3250 µl $326.00
$293.40
ADD TO CART
7727S Biotinylated Protein Ladder Detection Pack - 650 µl $92.00
$82.80
ADD TO CART
8112L SignalStain® Antibody Diluent - 100 ml $117.00
$105.30
ADD TO CART
8112S SignalStain® Antibody Diluent - 25 ml $57.00
$51.30
ADD TO CART
VIEW COMPANION PRODUCTS HIDE COMPANION PRODUCTS
Application Dilution Species-Reactivity Sensitivity MW (kDa) Isotype
W Human Endogenous 175 Rabbit IgG
IP
IHC-P
IF-P
IF-IC
F

Species cross-reactivity is determined by western blot.

Applications Key: W=Western Blotting, IP=Immunoprecipitation, IHC-P=Immunohistochemistry (Paraffin), IF-P=Immunofluorescence (Paraffin), IF-IC=Immunofluorescence (Immunocytochemistry), F=Flow Cytometry

Specificity / Sensitivity

EGFR (L858R Mutant Specific) (43B2) Rabbit mAb detects endogenous levels of EGFR mutant L858R protein. The antibody may cross-react with wildtype EGFR and other HER family members when highly over-expressed. Careful titration of this antibody may be required to obtain optimal specificity.

Source / Purification

Monoclonal antibody is produced by immunizing animals with a synthetic peptide corresponding to L858R mutant sequence of human EGF receptor.

Western Blotting

Western Blotting

Western blot analysis of extracts from various EGFR expressing cell lines, showing the specificity of detection of mutant EGFR (L858R) protein using EGF Receptor (L858R Mutant Specific) (43B2) Rabbit mAb (upper), and total EGFR control antibody (lower).

IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded H1975 (left, EGFR L858R positive) and H1650 xenograft (right, EGFR deletion positive) using EGF Receptor (L858R Mutant Specific) (43B2) Rabbit mAb (upper) and total EGFR (D38B1) XP® Rabbit mAb #4267 (lower).

IHC-P (paraffin)

IHC-P (paraffin)

Immunohistochemical analysis of paraffin-embedded human lung carcinoma of known mutational status using EGF Receptor (L858R Mutant Specific) (43B2) Rabbit mAb (upper) and total EGFR (D38B1) XP® Rabbit mAb #4267 (lower). EGFR L858R positive lung (left), EGFR deletion positive lung sections (right).


IF-P

IF-P

Confocal immunofluorescent analysis of paraffin-embedded H3255, H1975, HCC827 and H1650 xenografts using EGF Receptor (L858R Mutant Specific) (43B2) Rabbit mAb (upper, green) and EGFR (D38B1) XP® Rabbit mAb #4267 (lower, green). Blue pseudocolor = DRAQ5® #4084 (fluorescent DNA dye).

IF-IC

IF-IC

Confocal immunofluorescent analysis of H3255 (left), HCC827 (middle) and A431 cells (right) using EGF Receptor (L858R Mutant Specific) (43B2) Rabbit mAb (green) and MEK1/2 (L38C12) Mouse mAb #4694 (red). H3255 cells have the L858R EGFR mutation, HCC827 cells have an exon 19 EGFR deletion, and A431 cells overexpress wild type EGFR. Blue pseudocolor = DRAQ5® #4084 (fluorescent DNA dye).

Flow Cytometry

Flow Cytometry

Flow cytometric analysis of two non-small cell lung cancer cell lines using EGF Receptor (L858R Mutant Specific) (43B2) Rabbit mAb. H3255 cells (green) harbor the L858R EGFR mutation while the H1650 cells (blue) have the exon 19 mutation (delE746-A750).


Background

The epidermal growth factor (EGF) receptor is a 170 kDa transmembrane tyrosine kinase that belongs to the HER/ErbB protein family. Research studies have shown that somatic mutations in the tyrosine kinase domain of EGF receptor (EGFR) are present in a subset of lung adenocarinomas that respond to EGFR inhibitors, such as gefinitib and erlotinib (1-3). Two types of mutations account for approximately 90% of mutated cases: a specific point mutation, L858R, that occurs in exon 21 and short in-frame deletions in exon 19 (4,5). The most frequent exon 19 deletion is E746-A750, accounting for 90% of lesions at this site, although some rare variants occur.

  1. Lynch, T.J. et al. (2004) N Engl J Med 350, 2129-39.
  2. Pao, W. et al. (2004) Proc Natl Acad Sci USA 101, 13306-11.
  3. Haber, D.A. et al. (2005) Cold Spring Harb Symp Quant Biol 70, 419-26.
  4. Kosaka, T. et al. (2004) Cancer Res 64, 8919-23.
  5. Riely, G.J. et al. (2006) Clin Cancer Res 12, 7232-41.

Application References

  • Kawahara, A. et al. (2010) Clin Cancer Res , . Applications: IHC-P (paraffin), Western Blotting.
  • Simonetti, S. et al. (2010) J Transl Med 8, 135. Applications: IHC-P (paraffin).
  • Brevet, M. et al. (2010) J Mol Diagn 12, 169-76. Applications: IF-P (paraffin).
  • Yu, J. et al. (2009) Clin Cancer Res 15, 3023-8. Applications: IF-P (paraffin), IHC-P (paraffin), Western Blotting.
  • Rimkunas, V.M. et al. (2012) Clin Cancer Res 18, 4449-57. Applications: IHC-P (paraffin).
